Compressed Air Filter

SUPERIOR FILTRATION Proper filtration is necessary to ensure consistent air quality, but with it comes pressure drop. Every 2 psi of pressure drop increases power costs by 1%. Kaeser filters remove more contaminants with less pressure drop for lower operating costs. With a complete selection of application-specific filter types, sizes, technical service, and support, Kaeser offers a customized solution for all of your compressed air quality needs.

Additional information

Product Type

Filter

Features

  • Holds up to 34 filter elements
  • ASME pressure vessels, stamped and registered.
  • CRN numbers for many vessels and many Provinces – consult factory to confirm model and Province.
  • NPT(M) connections for 1000 to 1875 scfm models.
  • Flange connections 2500-21,250 scfm
  • ANSI pattern flanges for all models 2500 scfm and larger
  • 1 inch NPT(F) condensate drain port.
  • Maximum Allowable Working Pressure of 225 psig (without condensate drain)
  • Differential pressure indicator is standard.
  • Vessel access via 4” x 6” handhole

Product Brochure

SEE PDF

Specifications

ModelFilter TypeAir Flow @ 100 psig
(cfm)
Conn Sixe
(in)
Max Workinf Pressure
(psig)
Dimensions
(in)
Weight
(lb)
(Filter Type) - 1000PKLS Liquid Separator10003 NPTM22516 x 4890
KFS Filtered Separator10003 NPTM22516 x 4890
KPF Particulate Filter10003 NPTM22516 x 4890
KOR Oil Removal Filter10003 NPTM22516 x 4890
KOX Extra Fine Oil Removal Filter10003 NPTM22516 x 4890
KVF Vapor Filter10003 NPTM22516 x 4890
(Filter Type) - 1250PKLS Liquid Separator12503 NPTM22516 x 4890
KFS Filtered Separator12503 NPTM22516 x 4890
KPF Particulate Filter12503 NPTM22516 x 4890
KOR Oil Removal Filter12503 NPTM22516 x 4890
KOX Extra Fine Oil Removal Filter12503 NPTM22516 x 4890
KVF Vapor Filter12503 NPTM22516 x 4890
(Filter Type) - 1875PKLS Liquid Separator18753 NPTM22516 1/4 x 4990
KFS Filtered Separator18753 NPTM22516 1/4 x 4990
KPF Particulate Filter18753 NPTM22516 1/4 x 4990
KOR Oil Removal Filter18753 NPTM22516 1/4 x 4990
KOX Extra Fine Oil Removal Filter18753 NPTM22516 1/4 x 4990
KVF Vapor Filter18753 NPTM22516 1/4 x 4990
(Filter Type) - 2500PKLS Liquid Separator25004 Flange22520 x 52 1/4178
KFS Filtered Separator25004 Flange22520 x 52 1/4178
KPF Particulate Filter25004 Flange22520 x 52 1/4178
KOR Oil Removal Filter25004 Flange22520 x 52 1/4178
KOX Extra Fine Oil Removal Filter25004 Flange22520 x 52 1/4178
KVF Vapor Filter25004 Flange22520 x 52 1/4178
(Filter Type) - 3125PKLS Liquid Separator31254 Flange22520 x 52 1/4180
KFS Filtered Separator31254 Flange22520 x 52 1/4180
KPF Particulate Filter31254 Flange22520 x 52 1/4180
KOR Oil Removal Filter31254 Flange22520 x 52 1/4180
KOX Extra Fine Oil Removal Filter31254 Flange22520 x 52 1/4180
KVF Vapor Filter31254 Flange22520 x 52 1/4180
(Filter Type) - 5000PKLS Liquid Separator50006 Flange22524 x 54 5/8271
KFS Filtered Separator50006 Flange22524 x 54 5/8271
KPF Particulate Filter50006 Flange22524 x 54 5/8271
KOR Oil Removal Filter50006 Flange22524 x 54 5/8271
KOX Extra Fine Oil Removal Filter50006 Flange22524 x 54 5/8271
KVF Vapor Filter50006 Flange22524 x 54 5/8271
(Filter Type) - 6875PKLS Liquid Separator68756 Flange22528 x 62 9/16518
KFS Filtered Separator68756 Flange22528 x 62 9/16518
KPF Particulate Filter68756 Flange22528 x 62 9/16518
KOR Oil Removal Filter68756 Flange22528 x 62 9/16518
KOX Extra Fine Oil Removal Filter68756 Flange22528 x 62 9/16518
KVF Vapor Filter68756 Flange22528 x 62 9/16518
(Filter Type) - 8750PKC Moisture Separator87506 Flange22528 x 62 9/16525
KC Moisture Separator87506 Flange22528 x 62 9/16525
KC Moisture Separator87506 Flange22528 x 62 9/16525
KC Moisture Separator87506 Flange22528 x 62 9/16525
KC Moisture Separator87506 Flange22528 x 62 9/16525
KC Moisture Separator87506 Flange22528 x 62 9/16525
(Filter Type) - 11875PKLS Liquid Separator118758 Flange22533 x 69 1/8709
KFS Filtered Separator118758 Flange22533 x 69 1/8709
KPF Particulate Filter118758 Flange22533 x 69 1/8709
KOR Oil Removal Filter118758 Flange22533 x 69 1/8709
KOX Extra Fine Oil Removal Filter118758 Flange22533 x 69 1/8709
KVF Vapor Filter118758 Flange22533 x 69 1/8709
(Filter Type) - 16250PKLS Liquid Separator162508 Flange22539 x 68918
KFS Filtered Separator162508 Flange22539 x 68918
KPF Particulate Filter162508 Flange22539 x 68918
KOR Oil Removal Filter162508 Flange22539 x 68918
KOX Extra Fine Oil Removal Filter162508 Flange22539 x 68918
KVF Vapor Filter162508 Flange22539 x 68918
(Filter Type) - 21250PKLS Liquid Separator2125010 Flange22545 7/8 x 711412
KFS Filtered Separator2125010 Flange22545 7/8 x 711412
KPF Particulate Filter2125010 Flange22545 7/8 x 711412
KOR Oil Removal Filter2125010 Flange22545 7/8 x 711412
KOX Extra Fine Oil Removal Filter2125010 Flange22545 7/8 x 711412
KVF Vapor Filter2125010 Flange22545 7/8 x 711412
