Stanley Controllers

Stanley controller distributor
  • Availability of many different levels of use, from very basic to extremely sophisticated
  • Communication to the outside world via the Ethernet and other protocols
  • Error proofing – ensures that all fasteners installed on a given part
  • Traceability – storage of thousands of readings
  • Accountability – ability to record the operator using the tool
  • Data collection – storage of thousands of data points
  • Networkability

The Alpha Toolbox, included in every QBE Stanley Controller, is used for programming strategies, collect fastening cycle data, trace data, and performing online diagnostics of the tool and controller. The software enables tool configuration, tool diagnostics, data collection, and maintenance intervals. No set-up required, the software is executed from a serial connection to the controller or wirelessly on a tablet, phone or PC.

QBE Stanley Controllers include an Alpha Toolbox port, Assignable 24V DC I/O, a 24V DC mating connector, a power cord, and an optional plinth. The Wizard provides an easy method to control programming directly from the keypad on the controller or with Alpha Toolbox.

QBE Controller is the premier Single or Multi-Spindle Controller and Wireless Controller

  • Large touchscreen color display and on-screen keypad
  • QBE operates as a standalone controller or as the lead controller of multiple systems and manages up to 24 trailing spindles – Advanced or Nodes
  • An 802.11 b/g/n wireless access point for B-Series Stanley Cordless tools to connect as trailing spindles
  • Stores Trace Data for 30,000 Fastening Cycles
  • 99 jobs, 99 tasks, 12 steps – including smart steps and all advanced strategies
  • Include a USB port, a plant network Ethernet port, a Spindle network Ethernet port, a Serial port, Fieldbus options, an integrated PLC
  • 24V DC I/O, 8 Inputs / 8 Outputs, assignable

Specifications for Stanley QBE Controllers:

  • Dimensions (W x H x D): 15 cm x 36 cm x 26 cm (6in x 14 in x 10 in)
  • Weight: 7.6 kg (16.7 lb)
  • I/O Power Supply: 24V DC, 1A Internal, Ready for External Power Supply
  • AC Power Source: Auto Detect 100 – 126.5V or 200 – 253V AC, 50 or 60 Hz
  • Humidity: 0 to 95 % non-condensing
  • Temperature: 32-122 ºF (0-50 ºC)
